METART-WW25-Slot Hole Screening Mesh

Specification

Material: Stainless Steel 304 / Stainless Steel 316, SS201 and other alloys

Type: Rigid Wire Mesh

Opening Area: 42%

Weight: Approx 6.2kg/Square Meter

Finish: Mill Finish

Screen Width: Max 4000mm, Mill Finish only

Screen Length: up to 30 meters roll.

GET A QUOTE

Introduction

METART WW25 is just a type of dutch woven wire mesh, which typically has a greater warp wire density than weft wire density.
It is suitable for sieving mesh, shaker screens, solid material filtrations, and some architectural fencing or cladding projects.
Please refer to the following specifications.

Material	Stainless Steel 304 or 316, optional
Type	Rigid mesh
Wire Diameter	1.45mmx1.45mm
Clear Hole Size	1.6x5.6mm
Wire Pitch	3.1x7.1mm
The total thickness of the fabric	3.5mm
Opening Area	42%
Block out	58%
Privacy Rate	52%
Weight	6.2kg/Square Meter
Finish	Stainless Steel Mill Finish
The way of cutting	Straight Cut
All optional ways of cut	Straight Cut Only
All optional Finish	Mill Finish ( Original stainless steel bright finish）, Antique Bronze plating, Antique Copper plating, Antique brass plate, vacuum titanium plated, Painted, PVDF Coated,
Customized specifications and Mini order accepted.
Note: All the measurements including wire thickness, diameter, opening, and overall thickness are nominal numbers. The actual specification might have a tiny bit of tolerance according to fabrication
